Openwell Submersible Pumps
Robust openwell pump sets for continuous lifting from openwells and reservoirs.
Technical data sheet
Openwell Submersible Pump
Compact openwell submersible pumps engineered for direct installation in open wells, sumps, and reservoirs. Reliable performance for agriculture, domestic, light commercial, and industrial water supply with corrosion-resistant construction.
Characteristics
| Motor Rating | HP | 0.5 to 7.5 |
|---|---|---|
| kW | 0.37 to 5.5 | |
| Stages | No. | 1 to 4 |
| Head Range | Metres | 6 to 50 |
| Discharge | LPM | 60 to 1500 |
| Outlet | mm | 25 / 32 / 50 / 65 |
| inch | 1 / 1¼ / 2 / 2½ | |
| Speed | RPM | 2900 |
| Frequency | Hz | 50 |
| Supply | Volt | 200–240 (1Φ) / 380–415 (3Φ) |
| Installation | — | Direct openwell / sump |
| Applications | Use | Agriculture, Domestic, Industrial, Sprinkler, Light commercial water supply |
Material of Construction — Motor
- Stator: Vacuum impregnated, F class insulation
- Rotor: Aluminium pressure die-cast
- Motor body: Stainless steel SS-304
- Motor shaft: Stainless steel SS-420
- Mechanical seal: Carbon vs. ceramic, water lubricated
- Winding: EC grade copper, dual-coat F class
- Bearings: Sealed roller ball bearings
- Thermal protection: Built-in thermal overload protector
Material of Construction — Pump
- Pump casing: Cast iron, CED coated
- Impeller: Cast iron / brass / noryl options
- Suction strainer: Stainless steel mesh
- Pump shaft: Stainless steel SS-410
- Wearing rings: Abrasion-resistant stainless steel
- Fasteners: Stainless steel SS-304
- Cable: Submersible-grade flat cable (3-core)
Salient Features
- Direct openwell / sump installation — no priming required
- Compact, low-weight design for easy handling
- Water-lubricated mechanical seal for long life
- Stainless steel motor body for corrosion resistance
- Class F insulation with thermal overload protection
- Robust cast-iron pump casing with CED coating
- Single and three-phase variants available
- Quiet, vibration-free operation
Applications
- Open well & sump water supply
- Agricultural irrigation
- Domestic & residential water supply
- Light commercial water supply
- Industrial cooling water
- Sprinkler irrigation
- Water tank filling
Pump must remain fully submerged in water during operation.
Vertical or horizontal installation possible depending on model variant.
Have a question? Drop us a line.
Share your duty point — head, flow, voltage, application — and our engineering team will match the right configuration.
All configurations & variants
Compare specific models and variants in this category, or request a custom configuration via RFQ.
Openwell Submersible Pump
Premium openwell submersible pumping engineered for continuous duty, stable flow, and export-grade reliability across agriculture, utilities, and industrial water transfer.
Mini Openwell Submersible Pump
Compact openwell submersible pump designed for dependable lifting, energy-efficient operation, and simple handling in domestic, commercial, and light-agri use cases.
