Product overview
V5 — 125 mm (5") Borewell Submersible Pump Set from SUPERTECH WATER SOLUTION is engineered for B2B procurement where reliability, documentation, and lifecycle cost matter. This Borewell Submersible Pumps portfolio is built for government departments, EPC contractors, infrastructure companies, industrial plants, agricultural duty cycles, water treatment operators, and export buyers. We support projects across United States, Houston, Los Angeles, Miami, New York, India, Ahmedabad, Gujarat, UAE, Dubai, Saudi Arabia, Qatar, Oman, Kuwait, Bahrain, Africa.
Applications and industries served
Industrial procurement teams typically select V5 — 125 mm (5") Borewell Submersible Pump Set based on duty point, source conditions, water quality, voltage, and installation constraints. Common applications include: Medium-scale agricultural irrigation; Municipal water supply; Industrial process water; Fire fighting & pressure boosting; Mining dewatering. Industries served include infrastructure, municipal utilities, agriculture and irrigation, industrial manufacturing plants, builders and developers, and EPC project environments. For export projects, selection is aligned to spares availability, site serviceability, and documentation quality.
Key engineering features
SUPERTECH WATER SOLUTION focuses on consistent engineering fundamentals that matter in real installations: stable hydraulics, durable materials, robust electrical protection, and service-friendly assembly. Key highlights include: Radial and mixed-flow hydraulic options; Multi-stage configurations for high-head selection; Non-magnetic SS 304 motor body; Heavy-duty thrust bearing for sustained axial load. Our export-focused approach emphasises predictable performance and clearer documentation for faster tender evaluation and RFQ comparison.
Technical specifications for procurement
Technical selection is most accurate when duty point is defined — head, discharge, flow rate — along with installation parameters such as borewell diameter, installation depth, voltage, and phase. This product family supports configuration-based selection. Typical specification references include power rating, head range, capacity, pipe sizing, voltage band, material grades, and protection class. All published performance data is tested at 2880 RPM under nominal supply. Site-specific duty-point curves are supplied with every RFQ submission. If you need a customised datasheet for tender submission, request it via our RFQ page with your duty point and destination country.
How to select the right configuration
Correct selection begins with the system curve — total dynamic head (TDH) as a function of flow rate — not just the rated head at the catalogue duty point. TDH includes static head (vertical lift from water level to discharge point), friction losses in column pipe and surface pipework, and any residual pressure required at the delivery point. For borewell installations, the draw-down level under pumping conditions should be used, not the static water level. Motor type — Oil Filled (OF) versus Water Filled (WF) — is selected based on single-phase versus three-phase availability, required HP, and motor OD compatibility with the borewell casing diameter. Under-sizing causes overheating and premature motor failure; over-sizing wastes energy and increases capital cost. Use our RFQ form to share your duty point and receive a matched configuration with a performance curve.
Material of construction and corrosion resistance
Material selection is critical for long service life in varied water qualities — from clean municipal supply to sandy, brackish, or chemically aggressive borewell water. Key wetted parts are selected for resistance to abrasion, corrosion, and chemical attack. For applications in coastal areas, desert environments (UAE, Oman, Saudi Arabia), or high-chloride groundwater, the correct material grade significantly extends service intervals. When in doubt, specify the water quality — TDS, pH, sand content, and temperature — in your RFQ so the engineering team can confirm compatibility.
Voltage, frequency, and electrical compatibility
SUPERTECH WATER SOLUTION manufactures pump sets for both 50 Hz and 60 Hz supply to serve India and the GCC/international markets. For export to UAE, Saudi Arabia, Qatar, Oman, Kuwait, and Bahrain, 60 Hz variants are available. Confirm supply frequency, voltage band, and phase (single or three phase) at the time of RFQ. Wide voltage band motors are designed to start and operate under the supply fluctuations common in agricultural and rural installations. Refer to the datasheet for the operating voltage range of the specific model selected. For variable frequency drive (VFD) applications, confirm VFD compatibility during selection — not all motor configurations are intended for inverter duty without additional specification.
Installation and commissioning guidance
Correct installation is as important as correct selection. A well-selected pump set under-performs when installed incorrectly. Key installation requirements: the pump must be fully submerged to the minimum submergence depth specified in the datasheet; the motor cable must be correctly rated for submersible duty and the run length; and a motor protection device (overload relay, dry-run protector) must be fitted. The non-return valve (NRV) built into the pump prevents back-siphoning and reduces thrust load at switch-off — the surface NRV, if fitted, should be positioned correctly to avoid excessive back-pressure. Column pipe sizing directly affects friction loss and therefore effective head at the duty point. Under-sized column pipe is a common cause of underperformance.
Export documentation and compliance
For GCC and Africa markets, procurement teams require consistent, professional documentation aligned to EPC and government procurement standards. We support RFQ workflows with technical schedules, brochure packs, application notes, material test certificates (MTR), and pre-shipment inspection (SGS/BV) documentation. Compliance references include IS:8034-2002 (Water Filled motor pumpsets), ISO 9001:2015 quality management, SASO/SABER (Saudi Arabia), DEWA (Dubai/UAE), UL (North America), GOST (Russia/CIS), and BSTI (Bangladesh). Our team can assist with product comparison, recommended configuration, export packing specifications, and supply planning aligned to project milestones.
Serviceability, spares, and lifecycle value
Industrial buyers evaluate more than purchase price — they evaluate downtime risk and lifecycle support. SUPERTECH WATER SOLUTION designs product families with maintainability in mind: clear spares mapping, service access where practical, and cross-compatibility across common configurations within the same series. Spares packs covering wear parts (impellers, bowls, wearing rings, mechanical seals, thrust bearings) are available and can be included with the initial export shipment to reduce future downtime exposure at remote sites. When required, we align spares packs for export projects and EPC commissioning timelines.
B2B procurement FAQ
If you are comparing suppliers for 5 inch borewell submersible pump, focus on documentation clarity, performance transparency, and after-sales readiness. Ask for the exact configuration matching your duty point, request a technical table for comparison, and ensure the supplier can support export packing and lead times. Key questions: Does the supplier publish performance curves at the rated duty point, or only headline head and flow? Are material certificates available? Can the configuration be tested at the factory before shipment? Related searches covered by this page include: v5 submersible pump manufacturer, 125mm borewell pump supplier, 5 inch submersible pump price, industrial submersible pump exporter, 5 inch deep well pump USA. Our team supports these workflows for India and export markets across United States, Houston, Los Angeles, Miami, New York, India, Ahmedabad, Gujarat.
USA import and 60Hz electrical compatibility
SUPERTECH WATER SOLUTION actively exports V5 — 125 mm (5") Borewell Submersible Pump Set to the United States market, with 60Hz variants configured for North American electrical infrastructure. US electrical systems operate at 60Hz with common voltages of 110V (single-phase residential), 220V (single-phase commercial), and 460V (three-phase industrial). Our manufacturing supports all three voltage bands with NEMA frame-compatible motor configurations rated at 3450 RPM. For US procurement teams, all export documentation is prepared for US Customs and Border Protection (CBP) clearance, including HS Code classification (8413.70 for submersible pumps, 8501 for motors), Certificate of Origin (COO), commercial invoice with FOB/CIF terms, and packing list with net/gross weights. UL-ready engineering documentation, ANSI/NEMA specification compliance, and IEEE motor standards are maintained for US regulatory review. Factory test certificates and material test reports (MTR) are included with every shipment. We deliver to major US ports including Houston TX (Port of Houston), Los Angeles CA (Port of Long Beach), Newark NJ (Port New York/New Jersey), and Miami FL (PortMiami) via containerized ocean freight (FCL/LCL) with 21–35 day transit time. Payment terms for US buyers include wire transfer (TT), letter of credit (LC), and USD pricing. For distributor and OEM partnerships in the United States, contact our export sales desk for volume pricing and technical schedules.
