Technical data sheet
Horizontal Split-Case Pump
Horizontal axially-split casing centrifugal pump engineered for high-flow water transfer in municipal, fire-fighting (UL/FM ready), HVAC chilled water, and industrial cooling duties. Double-suction impeller for low NPSH and balanced axial thrust.
Characteristics
| Motor Rating | HP | 10 to 500 |
|---|---|---|
| kW | 7.5 to 375 | |
| Head Range | Metres | 20 to 200 |
| Discharge | LPM | 500 to 30000 |
| Suction | mm | 80 to 500 |
| inch | 3 to 20 | |
| Delivery | mm | 65 to 400 |
| inch | 2½ to 16 | |
| Speed | RPM | 1450 / 980 / 740 |
| Construction | — | Single-stage, double-suction, axially split casing |
| Flange standard | — | PN10 / PN16 / ANSI 125–250 |
| Applications | Use | Municipal water supply, Fire fighting (UL/FM), HVAC chilled water, Industrial cooling, Mining, Power plants |
Material of Construction — Hydraulic
- Casing: Cast iron / ductile iron / cast steel (option)
- Impeller: Bronze / SS 304 / SS 316 — closed double-suction
- Wear rings: Bronze / hardened SS — replaceable
- Shaft: Carbon steel EN-8 / SS 410
- Shaft sleeves: Stainless steel SS 410 / SS 316 — replaceable
- Mechanical seal: Carbon vs. SiC, EPDM / Viton secondary
- Bearings: Heavy-duty grease / oil lubricated ball bearings
- Coupling: Spacer coupling for back pull-out service
Material of Construction — Mounting & accessories
- Baseplate: Fabricated mild steel with drain pan, drilled
- Coupling guard: Mild steel, painted
- Gland water piping: Stainless steel tubing (for gland-packed variants)
- Pressure / vacuum gauges: Optional on suction & discharge
- Painting: Industrial epoxy enamel finish
Salient Features
- Axially-split casing — rotating element removed without disturbing piping
- Double-suction impeller — balanced axial thrust + low NPSH
- Mechanical seal as standard, soft-packed gland optional
- Robust shaft with replaceable shaft sleeves at seal area
- Heavy bronze / SS wear rings at impeller hub & eye
- Suitable for clean water up to 80 °C (higher with metallurgy upgrade)
- Mounted on common baseplate with spacer coupling
- Pressure-tested above maximum allowable working pressure (MAWP)
- VFD-friendly construction available
Applications
- Municipal water supply pumping stations
- Fire-fighting mains (UL/FM hydraulics on request)
- HVAC chilled / hot water mainlines for large complexes
- Industrial cooling water for plants & process
- Mining make-up water & dewatering mainlines
- Power plant condenser cooling water
- Irrigation & flood-control distribution
Specify duty point, liquid temperature, fluid SG, and starting method for accurate selection.
For fire-fighting duty, advise applicable code (NFPA 20, UL/FM, IS 12469) at RFQ stage.
